n8n on OpenShift: From Broken Template to AI Workflows with vLLM

I looked at a community PR from 2021 that tried to add an OpenShift deployment template to the n8n repo. It never got merged. The n8n maintainers closed it in 2023, saying they’d moved deployment templates into separate repos. But the template itself is interesting because it shows every mistake people make when porting a Docker Compose workflow to OpenShift.

Here’s what was in the PR, what breaks on a modern cluster, and how to fix it.

What the PR did

A contributor dropped an OpenShift Template into the n8n repo. It created four resources: a DeploymentConfig, a Service, a Route with TLS edge termination, and a PersistentVolumeClaim. You’d log into your cluster, process the template with a few parameters (URL, username, password, image, disk size), and get a running n8n instance.

On OpenShift 3.11, this probably worked fine. On a modern OCP 4.x cluster, it won’t even start.

The root problem

The container tries to run as root. The volume mount path is /root/.n8n, which tells you exactly what user the author expected. OpenShift doesn’t allow that. The default restricted Security Context Constraint blocks root containers, and for good reason. You’d have to grant the anyuid SCC to the service account, which your cluster admin will not appreciate.

Recent n8n images run as UID 1000 (the node user). The mount path should be /home/node/.n8n. That single change fixes the SCC problem without weakening cluster security.

DeploymentConfig is dead

The template uses DeploymentConfig, an OpenShift-specific resource that predates the Kubernetes Deployment API. Red Hat deprecated it in OCP 4.14. It still functions, but new workloads should use apps/v1 Deployment. The migration is straightforward: drop the OpenShift-specific fields (test: false, the deploymentconfig labels), switch the apiVersion and kind, and replace spec.triggers with standard image update mechanisms if you need them.

One gotcha: the Service in the template selects on deploymentconfig: n8n-server. Once you switch to a Deployment, that label won’t exist unless you add it manually. Simpler to change the selector to app: n8n-server, which both resource types use.

Credentials in plain sight

The template injects the n8n username and password as raw environment variables. Anyone with oc get dc n8n-server -o yaml access can read them. The fix is a Secret:

apiVersion: v1
kind: Secret
metadata:
  name: n8n-credentials
type: Opaque
stringData:
  username: admin
  password: changeme

Then reference it from the container spec with secretKeyRef instead of hardcoding the values.

But there’s a bigger issue. The environment variables this template sets (N8N_BASIC_AUTH_ACTIVE, N8N_BASIC_AUTH_USER, N8N_BASIC_AUTH_PASSWORD) were removed from n8n in version 0.200. They do nothing now. n8n switched to built-in user management, so you configure the initial admin through the web UI on first launch. The entire auth section of this template is dead code.

The small stuff that adds up

The template has type: Recreate for the deployment strategy but includes rollingParams with surge and unavailable percentages. Recreate ignores those fields. It’s not broken, but it’s confusing. Pick one.

resources: {} means no CPU or memory requests. If your namespace has a ResourceQuota (most production namespaces do), the pod will be rejected at admission. Set actual values. For n8n, something like 256Mi memory request and 512Mi limit is a reasonable starting point.

No readiness or liveness probes. n8n exposes /healthz. Use it. Without probes, the Route will send traffic to the pod before n8n finishes loading, and OpenShift has no way to restart it if it deadlocks.

The timezone is hardcoded to Europe/Hungary, which is not a valid IANA timezone identifier. The correct one is Europe/Budapest. Also, the YAML wraps it in extra quotes ('"Europe/Hungary"'), so the actual value the container sees includes literal quote characters. It should be a template parameter with a valid default.

Every parameter has diplayName instead of displayName. Minor, but it means the OpenShift console won’t show friendly labels when you fill in the form.

What I actually built instead

I used Kustomize with a base/overlay split. The base layer has portable Kubernetes resources (Deployment, Service, PVC, ConfigMap). The OpenShift overlay adds a TLS Route and patches in the security context.

Here’s the shape of the Deployment:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: n8n
spec:
  replicas: 1
  strategy:
    type: Recreate
  template:
    spec:
      securityContext:
        runAsNonRoot: true
        fsGroup: 1000780000
        seccompProfile:
          type: RuntimeDefault
      containers:
        - name: n8n
          image: docker.n8n.io/n8nio/n8n:latest
          ports:
            - containerPort: 5678
          envFrom:
            - configMapRef:
                name: n8n-config
          resources:
            requests:
              memory: 256Mi
              cpu: 100m
            limits:
              memory: 512Mi
              cpu: 500m
          readinessProbe:
            httpGet:
              path: /healthz
              port: 5678
            initialDelaySeconds: 15
          livenessProbe:
            httpGet:
              path: /healthz
              port: 5678
            initialDelaySeconds: 30
          securityContext:
            allowPrivilegeEscalation: false
            capabilities:
              drop:
                - ALL
          volumeMounts:
            - name: data
              mountPath: /home/node
      volumes:
        - name: data
          persistentVolumeClaim:
            claimName: n8n-data

The full manifests are in the n8n-openshift repo under base/ and overlays/openshift/.

What broke during testing (and the fixes)

I deployed this to a live OpenShift 4.x sandbox cluster. Three things failed before it worked.

First crash: EACCES: mkdir '/.n8n'. OpenShift’s random UID has no home directory, so ~ resolves to /. n8n tried to create its data directory at the filesystem root. Fix: set N8N_USER_FOLDER=/home/node in the ConfigMap so n8n writes to the PVC mount instead.

Second crash: EACCES: mkdir '/home/node/.n8n'. The PVC was mounted at /home/node/.n8n, but the random UID couldn’t create that directory because its parent /home/node was root-owned. Fix: mount the PVC at /home/node (the parent) and let n8n create the .n8n subdirectory inside the writable volume.

Third crash: volume not writable. Even with the correct mount path, the PVC’s root filesystem was owned by root:root with 755 permissions. The random UID couldn’t write. Fix: add fsGroup to the pod security context, using the first value from the namespace’s supplemental groups range. This makes OpenShift chgrp the volume to the pod’s group at mount time.

After those three fixes, n8n v2.7.5 booted, ran its SQLite migrations, and the health endpoint returned 200 through the Route.

Why OpenShift and not just Kubernetes

If the base Kustomize layer works on vanilla Kubernetes, why bother with the OpenShift overlay?

Getting n8n running is the easy bit. What’s more interesting is what’s already on the cluster when you get there.

If your organization runs OpenShift AI, you already have KServe and vLLM serving models. Granite, Llama, Mistral, whatever your team picked. Those models expose OpenAI-compatible /v1/chat/completions endpoints on internal Service URLs. n8n can call them over the cluster network without any extra infrastructure. No ingress, no public exposure, no separate API gateway.

GPU scheduling is the same story. The NVIDIA GPU Operator or AMD ROCm support handles time-slicing and MIG partitioning. Model inference pods get GPU resources through standard Kubernetes resource requests. n8n doesn’t touch GPUs; it calls an HTTP endpoint. But having both on the same cluster means lower latency and zero egress costs.

OpenShift projects also give you namespace isolation with network policies by default. Your n8n instance can reach your model serving endpoints but not someone else’s. On vanilla Kubernetes, you’d wire that up yourself.

And TLS is automatic. The Route gets a valid certificate from the cluster’s wildcard cert. Service-to-service traffic uses the internal CA. Nothing to manage.

Connecting n8n to vLLM on the same cluster

If you have vLLM running on the same cluster, whether standalone or through OpenShift AI, the model exposes an OpenAI-compatible API. n8n calls it. Simple enough in theory.

In practice, I hit a snag. I tested with a LiteLLM proxy fronting a DeepSeek R1 model. The curl worked:

curl -X POST https://litellm-proxy.apps.example.com/v1/chat/completions \
  -H "Authorization: Bearer $API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "DeepSeek-R1-Distill-Qwen-14B-W4A16",
    "messages": [{"role": "user", "content": "Hello"}]
  }'

The response came back with reasoning content and everything. But n8n’s OpenAI node returned a 404: litellm.NotFoundError: Received Model Group=DeepSeek-R1-Distill-Qwen-14B-W4A16. Same model name, same endpoint.

n8n’s OpenAI node does its own request construction and model validation internally. It doesn’t always agree with OpenAI-compatible proxies that aren’t literally OpenAI. I stopped debugging the node and just used an HTTP Request node instead:

1. Method: POST
2. URL: https://your-vllm-or-litellm-endpoint/v1/chat/completions
3. Authentication: Header Auth with Authorization: Bearer <key>
4. Body: raw JSON with model name and messages

This mirrors the curl exactly. You lose n8n’s AI-specific node features (message history, agent loops), but you control exactly what gets sent. For most automation use cases, an HTTP Request node that does what you expect beats an AI node that quietly rewrites your request.

What you can actually build with this

Once n8n and your models share a cluster, a specific category of automation becomes easy to build. The kind that normally requires writing a custom Python service, standing up a queue, and maintaining a deployment pipeline for what amounts to glue code.

A webhook fires when a support ticket lands. n8n extracts the text, sends it to a Llama model for classification, routes the ticket to the right team, posts a summary to Slack. Every step is visible in the n8n canvas. The whole thing is maybe 8 nodes.

If you’re running a vector database (Milvus, Qdrant, pgvector) on the same cluster, n8n can orchestrate a full RAG loop: receive a question, query the vector store, format the context, call the model, return the answer. All traffic stays inside the cluster.

There’s also the operational stuff. Schedule a workflow to periodically send test prompts to your models and check the responses. Compare outputs across model versions. Log the results. Too small for a dedicated MLOps platform, too important to do by hand.

If you’re running Meta’s Llama Stack on OpenShift, it exposes REST APIs for inference, safety, memory, and agent orchestration. n8n calls these the same way it calls vLLM. You can check inputs through the safety API before they reach the model, maintain conversation context across workflow executions through the memory API, or let Llama Stack’s agent API handle multi-turn tool-calling loops while n8n acts as the trigger and routing layer.

And with LiteLLM as a proxy (which OpenShift AI uses for model routing), n8n can target different models for different tasks in the same workflow. Classification goes to a small, fast model. Summarization goes to a larger one. Code generation to something else. Each is a different model value in the HTTP Request body.

The stack

From bottom to top:

OpenShift cluster
  |
  +-- GPU nodes with NVIDIA Operator
  |     |
  |     +-- vLLM / KServe InferenceService (your models)
  |     +-- Llama Stack server (optional, for safety/memory/agents)
  |
  +-- CPU nodes
        |
        +-- n8n (this deployment)
        +-- LiteLLM proxy (model routing, optional)
        +-- Vector DB (RAG, optional)
        +-- PostgreSQL (n8n backend, for multi-replica)

n8n runs on CPU nodes. It calls model serving endpoints over the internal network. Routes expose n8n to users. Everything else stays internal.

The separation is the point. n8n decides when to call what and where to send the output. The model servers handle inference. If you swap vLLM for TGI, or replace Llama 3 with Granite, n8n doesn’t care. You change a URL and a model name.

Summary of changes from the original PR

Issue	Original	Fix
Resource type	DeploymentConfig	Deployment (apps/v1)
Container user	root (/root/.n8n)	non-root (/home/node)
Credentials	Plain env vars	Remove (deprecated since n8n 0.200)
Timezone	”Europe/Hungary” (invalid)	UTC, configurable
Resources	None set	Requests and limits
Health checks	None	readinessProbe + livenessProbe on /healthz
Strategy	Recreate with rollingParams	Recreate (clean)
Service selector	deploymentconfig label	app label
Template format	OpenShift Template	Kustomize base + overlay
Volume permissions	Assumed root	fsGroup from namespace range

The deployment gets n8n on your cluster. The payoff is connecting it to the AI infrastructure that’s already there and replacing custom services with workflow nodes you can see and edit.
